特性項目 | 特性規格 | 引用標準 | ||
外 觀 | 表面光潔、色澤均勻、無松散 | DIN VDE 0250-502 DIN VDE 0282-1:1999.01 DIN VDE 0282-2:1999.01 | ||
火花試驗 | AC6KV/ 0.15 S | |||
耐壓測試 | 2 KV/5 min | |||
絕緣 機械 性能 | 老化前 | 抗張強度 | ≥5.0N/mm2 | |
斷裂伸長率 | ≥150% | |||
老化后 | 抗張強度 | ≥4.0N/mm2 | ||
(200±3℃×240h) | 斷裂伸長率 | ≥120% | ||
有害物質控制 | 符合ROHS指令 | 歐盟—2002/95/EC | ||
| H05SS-F結構尺寸附表 | ||||||||
芯數×截面 | 線芯結構 | 絕 緣 | 護套厚度 | 電線外徑 | 20℃時導體電阻 Ω/KM不大于 | |||
厚度 | 外徑 | 標稱 | 公差 | |||||
mm2 | 根/直徑 mm | mm | mm | mm | mm | mm | 銅芯 | 鍍錫銅絲 |
2×0.75 | 24/0.20 | 0.6 | 2.35 | 0.8 | 6.3 | ±0.20 | 26.0 | 26.7 |
3×0.75 | 24/0.20 | 0.6 | 2.35 | 0.9 | 6.9 | ±0.25 | 26.0 | 26.7 |
4×0.75 | 24/0.20 | 0.6 | 2.35 | 0.9 | 7.5 | ±0.30 | 26.0 | 26.7 |
5×0.75 | 24/0.20 | 0.6 | 2.35 | 1.0 | 8.4 | ±0.30 | 26.0 | 26.7 |
6×0.75 | 24/0.20 | 0.6 | 2.35 | 1.0 | 8.6 | ±0.30 | 26.0 | 26.7 |
7×0.75 | 24/0.20 | 0.6 | 2.35 | 1.0 | 9.1 | ±0.30 | 26.0 | 26.7 |
2×1 | 32/0.20 | 0.6 | 2.55 | 0.9 | 6.9 | ±0.25 | 19.5 | 20.0 |
3×1 | 32/0.20 | 0.6 | 2.55 | 0.9 | 7.3 | ±0.30 | 19.5 | 20.0 |
4×1 | 32/0.20 | 0.6 | 2.55 | 0.9 | 8.0 | ±0.30 | 19.5 | 20.0 |
5×1 | 32/0.20 | 0.6 | 2.55 | 1.0 | 8.9 | ±0.30 | 19.5 | 20.0 |
6×1 | 32/0.20 | 0.6 | 2.55 | 1.0 | 9.2 | ±0.30 | 19.5 | 20.0 |
7×1 | 32/0.20 | 0.6 | 2.55 | 1.0 | 9.7 | ±0.30 | 19.5 | 20.0 |
2×1.5 | 30/0.25 | 0.8 | 3.2 | 1.0 | 8.4 | ±0.30 | 13.3 | 13.7 |
3×1.5 | 30/0.25 | 0.8 | 3.2 | 1.0 | 8.9 | ±0.30 | 13.3 | 13.7 |
4×1.5 | 30/0.25 | 0.8 | 3.2 | 1.1 | 10.0 | ±0.30 | 13.3 | 13.7 |
5×1.5 | 30/0.25 | 0.8 | 3.2 | 1.1 | 10.9 | ±0.30 | 13.3 | 13.7 |
6×1.5 | 30/0.25 | 0.8 | 3.2 | 1.1 | 11.2 | ±0.30 | 13.3 | 13.7 |
7×1.5 | 30/0.25 | 0.8 | 3.2 | 1.1 | 11.9 | ±0.30 | 13.3 | 13.7 |
2×2.5 | 50/0.25 | 0.9 | 3.8 | 1.1 | 9.8 | ±0.30 | 7.98 | 8.21 |
3×2.5 | 50/0.25 | 0.9 | 3.8 | 1.1 | 10.5 | ±0.30 | 7.98 | 8.21 |
4×2.5 | 50/0.25 | 0.9 | 3.8 | 1.2 | 11.6 | ±0.30 | 7.98 | 8.21 |
5×2.5 | 50/0.25 | 0.9 | 3.8 | 1.3 | 12.9 | ±0.30 | 7.98 | 8.21 |
6×2.5 | 50/0.25 | 0.9 | 3.8 | 1.3 | 13.3 | ±0.30 | 7.98 | 8.21 |
7×2.5 | 50/0.25 | 0.9 | 3.8 | 1.3 | 14.1 | ±0.30 | 7.98 | 8.21 |
2×4 | 56/0.30 | 1.0 | 4.7 | 1.2 | 11.8 | ±0.30 | 4.95 | 5.09 |
3×4 | 56/0.30 | 1.0 | 4.7 | 1.2 | 12.6 | ±0.30 | 4.95 | 5.09 |
4×4 | 56/0.30 | 1.0 | 4.7 | 1.3 | 14.0 | ±0.30 | 4.95 | 5.09 |
5×4 | 56/0.30 | 1.0 | 4.7 | 1.5 | 15.7 | ±0.30 | 4.95 | 5.09 |
6×4 | 56/0.30 | 1.0 | 4.7 | 1.8 | 16.8 | ±0.40 | 4.95 | 5.09 |
7×4 | 56/0.30 | 1.0 | 4.7 | 1.8 | 17.8 | ±0.40 | 4.95 | 5.09 |
2×6 | 84/0.30 | 1.0 | 5.3 | 1.4 | 13.4 | ±0.30 | 3.3 | 3.39 |
3×6 | 84/0.30 | 1.0 | 5.3 | 1.4 | 14.3 | ±0.30 | 3.3 | 3.39 |
4×6 | 84/0.30 | 1.0 | 5.3 | 1.5 | 15.8 | ±0.30 | 3.3 | 3.39 |
5×6 | 84/0.30 | 1.0 | 5.3 | 1.8 | 18.0 | ±0.40 | 3.3 | 3.39 |
6×6 | 84/0.30 | 1.0 | 5.3 | 2.0 | 18.9 | ±0.40 | 3.3 | 3.39 |
7×6 | 84/0.30 | 1.0 | 5.3 | 2.0 | 20.0 | ±0.50 | 3.3 | 3.39 |
H05SST-F結構尺寸附表 | ||||||||||
芯數×截面 | 線芯結構 | 絕緣 | 護套 | 電線外徑 | 20℃時導體電阻 Ω/KM不大于 | |||||
厚度 | 外徑 | 厚度 | 外徑 | 編織厚度 | 標稱 | 公差 | ||||
mm2 | 根/直徑 mm | mm | mm | mm | mm | mm | mm | mm | 銅芯 | 鍍錫銅絲 |
2×0.75 | 24/0.20 | 0.6 | 2.35 | 0.8 | 6.3 | 0.25 | 6.8 | ±0.25 | 26.0 | 26.7 |
3×0.75 | 24/0.20 | 0.6 | 2.35 | 0.9 | 6.9 | 0.25 | 7.4 | ±0.30 | 26.0 | 26.7 |
4×0.75 | 24/0.20 | 0.6 | 2.35 | 0.9 | 7.5 | 0.25 | 8.0 | ±0.40 | 26.0 | 26.7 |
5×0.75 | 24/0.20 | 0.6 | 2.35 | 1.0 | 8.4 | 0.25 | 8.9 | ±0.40 | 26.0 | 26.7 |
2×1 | 32/0.20 | 0.6 | 2.55 | 0.9 | 6.9 | 0.25 | 7.4 | ±0.30 | 19.5 | 20.0 |
3×1 | 32/0.20 | 0.6 | 2.55 | 0.9 | 7.3 | 0.25 | 7.8 | ±0.40 | 19.5 | 20.0 |
4×1 | 32/0.20 | 0.6 | 2.55 | 0.9 | 8.0 | 0.25 | 8.5 | ±0.40 | 19.5 | 20.0 |
5×1 | 32/0.20 | 0.6 | 2.55 | 1.0 | 8.9 | 0.25 | 9.4 | ±0.40 | 19.5 | 20.0 |
2×1.5 | 30/0.25 | 0.8 | 3.2 | 1.0 | 8.4 | 0.25 | 8.9 | ±0.40 | 13.3 | 13.7 |
3×1.5 | 30/0.25 | 0.8 | 3.2 | 1.0 | 8.9 | 0.25 | 9.4 | ±0.40 | 13.3 | 13.7 |
4×1.5 | 30/0.25 | 0.8 | 3.2 | 1.1 | 10.0 | 0.25 | 10.5 | ±0.40 | 13.3 | 13.7 |
5×1.5 | 30/0.25 | 0.8 | 3.2 | 1.1 | 10.9 | 0.25 | 11.4 | ±0.40 | 13.3 | 13.7 |
2×2.5 | 50/0.25 | 0.9 | 3.8 | 1.1 | 9.8 | 0.25 | 10.3 | ±0.40 | 7.98 | 8.21 |
3×2.5 | 50/0.25 | 0.9 | 3.8 | 1.1 | 10.4 | 0.25 | 10.9 | ±0.40 | 7.98 | 8.21 |
4×2.5 | 50/0.25 | 0.9 | 3.8 | 1.2 | 11.6 | 0.25 | 12.1 | ±0.40 | 7.98 | 8.21 |
5×2.5 | 50/0.25 | 0.9 | 3.8 | 1.3 | 12.9 | 0.25 | 13.4 | ±0.50 | 7.98 | 8.21 |
3×4 | 56/0.30 | 1.0 | 4.7 | 1.2 | 12.6 | 0.25 | 13.1 | ±0.50 | 4.95 | 5.09 |
4×4 | 56/0.30 | 1.0 | 4.7 | 1.3 | 14.0 | 0.30 | 14.6 | ±0.50 | 4.95 | 5.09 |
3×6 | 84/0.30 | 1.0 | 5.3 | 1.4 | 14.3 | 0.30 | 14.9 | ±0.50 | 3.3 | 3.39 |
4×6 | 84/0.30 | 1.0 | 5.3 | 1.5 | 15.8 | 0.30 | 16.4 | ±0.50 | 3.3 | 3.39 |
